Trimax NH CONE Crushers
TERTIARY CRUSHING FOR MINING & QUARRYING
SIMPLY BETTER CRUSHERS
TRIMAX NH CONE CRUSHERS
Trimax NH Cone Crushers are suitable for a wide range of tertiary crushing applications in the mining, aggregate quarrying and associated crushing industries.
With more than 150 units already in operation, Trimax cone crushers are high-speed crushers of proven and advanced design with a small foot-print and high capacity in relation to their size, that will astound the most skeptical critics.
Our cone crushers have a wide range of use. With different crushing chamber profiles and eccentric throws, Trimax cone crushers can easily match to changes to production requirements and specifications.
Trimax NH Series Cone Crushers are an excellent choice for tertiary crushing functions when coupled with use with a secondary cone crusher and even functions as a 4th crusher when required.
Without a doubt, Trimax Series Cone Crushers have an in-built flexibility that will allow you to cope with changing production requirements for many years to come. Coupled with stringent requirements for high quality & durable quality parts, the NH series of High-Speed Cone Crushers are more than capable in meeting the challenges of today’s most demanding quarrying and crushing applications.
OPTIONAL CONE CRUSHER ADD-ON
Optional Automated Control Setting System (ACS) is available to optimise your Trimax NS Cone Crusher’s crushing capacity and provide additional protection.
Automated Control System (ACS)
Benefits
Today’s customers have to maximise return on investment. This means not only achieving the maximum throughput from their crushers but hacing control in a way that maximises the quality and volume of saleable products, while reducing maintenance costs especially unplanned and expensive traumatic failure. To achieve this, the customer has to have control especially of the setting at which the crusher operates. This can only be accomplished with a setting control system such as the Trimax ACS.
| MODEL | MOTOR KW (HP) | CLOSED SIDE SETTING MM | CAPACITY TPH |
|---|---|---|---|
|
NH300 |
160 (215) |
6 - 38 |
70 - 190 |
|
NH400 |
220 (295) |
6 - 44 |
95 - 305 |
|
NH600 |
315 (422) |
10 - 44 |
210 - 590 |
